Image Sensor
1/3" Progressive Scan CMOS sensor
Day & NightICR type
-
Focal Length
4mm / 6mm
Aperture4mm: F2.2
6mm: F2.0FOVHorizontal FOV(4mm): 79.1°, Vertical FOV: 43.3°, Diagonal FOV: 94.9°
Horizontal FOV(6mm): 49.9°, Vertical FOV: 27.7°, Diagonal FOV: 57.6° -
Supplementary Light
2 IR Lights, 2 Spotlights
Supplementary Light DistanceUp to 30 m/100 ft (depending on environment)
IR Wavelength850nm
Night Vision ModeSmart Mode, Full Color Mode, Black & White Mode
-
Video Encoding Format
H.265, H.264
Main Stream Resolution2560 ×1440, 2304 ×1296, 1920 × 1080
Sub Stream Resolution640 × 360, 352 × 288, 320 × 240
Frame Rate1-25fps, Default 25fps
Bit Rate256kbps -- 8192kbps
Bit Rate ControlCBR,VBR
-
Audio Encoding Format
G.711A
Audio Sampling Rate8 kHz
-
Image Enhancement
DWDR, BLC, HLC, 3D DNR
Privacy Mask4 Areas
-
Ethernet Port
1 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet port
ONVIFSupport
ProtocolsTCP/IP, UDP, ICMP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP
Web BrowserPlug-in free live view: Chrome, Edge, Opera
-
Smart Detection
Motion Detection, Human Detection
-
Audio Input
Built-in MIC
-
Power
12 V DC, 1A, Ø5.5mm&Ø2.1mm Power Plug
PoE: IEEE 802.3afCasing MaterialPlastic
Product Dimension85mm x 85mm x 166mm(3.3" × 3.3" × 6.5")
Package Dimension180mm x 122mm x 95mm(7.1" × 4.8" × 3.7")
Product Weight239g (0.53lb)
With Package Weight380g (0.84lb)
Protection LevelIP66
Installation MethodWall Mounting, Ceiling Mounting, Pole Mounting (Additional Bracket is Required)
CertificationCE, FCC, RoHS
TemperatureOperating Temperature: -30°C ~ 60°C (-22°F ~ 140°F)
Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F)HumidityOperating Humidity: 10% ~ 95% RH (non-condensing)
Storage Humidity: 3% ~ 95% RH (non-condensing)Package ContentsCamera
Waterproof Kit
Quick Installation Guide
- Model: IT7-PRS-4
- SKU: IT7-PRS-4
-
