Model
i24
CategoryCeiling
Dimension178 × 178 × 38mm
-
Interface
One 10/100/1000 Mbps Ethernet Port (PoE)
Button1 x RESET
LED Indicator1 x SYS
Maximum Power Consumption13.5W
Power Supply802.3af/at & DC: 12V 1A
Max. Number of Clients256
Recommended Clients40
Antenna2.4GHz: 2 x 4dBi
5GHz: 2 x 4dBi2.4GHz maximum power23+/-1.5dBm
5GHz maximum power23+/-1.5dBm
Reception Sensitivity802.11b -93 dBm
2.4 GHz 802.11n (MCS7)
-73dBm
5 GHz 802.11a -93 dBm
5 GHz 802.11n (MCS7)
-74 dBmFrequency Range2.4GHz&5GHz
Standard&Protocol802.11a/b/g/n/ac(wave2)
Maximum wireless speed2.4GHz: 300Mbps
5GHz: 867MbpsBandwidth20MHz/40MHz/80MHz
-
Operating Mode
AP/Client AP
Max. No. of SSID2.4GHz: 8
5GHz: 4Hide SSIDSupport
OFDMASupport
BeamformingSupport
Fast roaming（802.11k/v/r）Support
WEPSupport
WPA-PSKSupport
WPA2-PSKSupport
WPASupport
WPA2Support
WPA3-ASESupport
Access controlSupport
Adjustable power transmitSupport
Automatic channelSupport
AP isolationSupport
Connected clients controlSupport
RSSI ThresholdSupport
Weak signal terminal eliminationSupport
Prioritize 5 GHzSupport
VLAN tagging for SSIDSupport
LED controlSupport
MU-MIMOSupport
Diagnostics toolSupport
Reboot at specified intervalSupport
Schedule RebootSupport
Device managementM3 or Tenda Router with AP Controller feature
System LogsSupport
Firmware upgradeSupport
RebootSupport
ResetSupport
Backup configurationSupport
Restore configurationSupport
-
Default login IP
192.168.0.254
Operation Temperature-10℃ ~ 40℃
Operating humidity10%~90% non-condensing
Storage temperature-30℃ ~ 70℃
Storage humidity10%~90% non-condensing
- Model: I24
- SKU: I24
-
